Hardware Specifications
CPU / Memory
• CPU: ATMEL 536MHz ATSAMA5D35 w/MMU
• SDRAM: 512MB,LPDDR2• Flash: 8GB,eMMC
Network Interface
• Type: 1 x Gigabit and 1 x 10/100Mbps Ethernet
• Connector Type: RJ45
Serial Port Common Parameters
• Baud Rate: up to 921.6Kbps
• Parity: None , Even , Odd , Mark , Space
• Data Bits: 5,6,7,8
• Stop Bits: 1,1.5,2
• Flow Control: RTS/CTS , XON/XOFF , None
Serial Ports
• RS-232 or RS-485 , software select
• RS-232 Signals: TX , RX , RTS , CTS
• RS-485 Signals : Data+ , Data-
• RS-485 Automatic Flow Control: Yes
Console / Debug Ports
• Support micro USB console port
General
• Real time clock: Yes , backup by LITHIUM BATTERY
• Buzzer: Yes
• Watchdog: Yes
• Dimensions(WxHxD):78x108x24mm
• OperatingTemperature: 0~70°C(32~158°F)
Software Specifications
Operation System
• Linux kernel 3.18.xx with Ext4 filesystem
• Supports bootup from eMMC or SDcard
Software Development
• Toolchain: gcc5.20+glibc2.22
• Supports in-place C/C++ code compilation
Software Development
• Toolchain: gcc5.20+glibc2.22
• Supports in-place C/C++ code compilation
